Chapter 7. Soft Introduction to Hadoop

Table of Contents

7.1. Hadoop = HDFS + MapReduce
7.2. Why Hadoop?
7.3. Meet the Hadoop Zoo
HDFS - Hadoop Distributed File System
HBase, the database for Big Data
Hive - data warehousing
Pig - Big Data manipulation
7.4. Hadoop alternatives
Large data storage alternatives
Large database alternatives
7.5. Alternatives for distributed massive computations
7.6. Arguments for Hadoop

7.1. Hadoop = HDFS + MapReduce

Hadoop provides two things : Storage & Compute. If you think of Hadoop as a coin, one side is storage and other side is compute.

Figure 7.1. Hadoop coin

Hadoop coin

In Hadoop speak, storage is provided by Hadoop Distributed File System (HDFS). Compute is provided by MapReduce.

Hadoop is an open-source implementation of Google's distributed computing framework (which is proprietary). It consists of two parts: Hadoop Distributed File System (HDFS), which is modeled after Google's GFS, and Hadoop MapReduce, which is modeled after Google's MapReduce.

MapReduce is a programming framework. Its description was published by Google in 2004. Much like other frameworks, such as Spring, Struts, or MFC, the MapReduce framework does some things for you, and provides a place for you to fill in the blanks. What MapReduce does for you is to organize your multiple computers in a cluster in order to perform the calculations you need. It takes care of distributing the work between computers and of putting together the results of each computer's computation. Just as important, it takes care of hardware and network failures, so that they do not affect the flow of your computation. You, in turn, have to break your problem into separate pieces which can be processed in parallel by multiple machines, and you provide the code to do the actual calculation.

7.2. Why Hadoop?

We have already mentioned that the Hadoop is used at Yahoo and Facebook. It has seen rapid uptake in finance, retail, telco, and the government. It is making inroads into life sciences. Why is this?

Figure 7.2. Will you join the Hadoop dance?

Will you join the Hadoop dance?

The short answer is that it simplifies dealing with Big Data. This answer immediately resonates with people, it is clear and succinct, but it is not complete. The Hadoop framework has built-in power and flexibility to do what you could not do before. In fact, Cloudera presentations at the latest O'Reilly Strata conference mentioned that MapReduce was initially used at Google and Facebook not primarily for its scalability, but for what it allowed you to do with the data.

In 2010, the average size of Cloudera's customers' clusters was 30 machines. In 2011 it was 70. When people start using Hadoop, they do it for many reasons, all concentrated around the new ways of dealing with the data. What gives them the security to go ahead is the knowledge that Hadoop solutions are massively scalable, as has been proved by Hadoop running in the world's largest computer centers and at the largest companies.

As you will discover, the Hadoop framework organizes the data and the computations, and then runs your code. At times, it makes sense to run your solution, expressed in a MapReduce paradigm, even on a single machine.

But of course, Hadoop really shines when you have not one, but rather tens, hundreds, or thousands of computers. If your data or computations are significant enough (and whose aren't these days?), then you need more than one machine to do the number crunching. If you try to organize the work yourself, you will soon discover that you have to coordinate the work of many computers, handle failures, retries, and collect the results together, and so on. Enter Hadoop to solve all these problems for you. Now that you have a hammer, everything becomes a nail: people will often reformulate their problem in MapReduce terms, rather than create a new custom computation platform.

No less important than Hadoop itself are its many friends. The Hadoop Distributed File System (HDFS) provides unlimited file space available from any Hadoop node. HBase is a high-performance unlimited-size database working on top of Hadoop. If you need the power of familiar SQL over your large data sets, Pig provides you with an answer. While Hadoop can be used by programmers and taught to students as an introduction to Big Data, its companion projects (including ZooKeeper, about which we will hear later on) will make projects possible and simplify them by providing tried-and-proven frameworks for every aspect of dealing with large data sets.

As you learn the concepts, and perfect your skills with the techniques described in this book you will discover that there are many cases where Hadoop storage, Hadoop computation, or Hadoop's friends can help you. Let's look at some of these situations.

  • Do you find yourself often cleaning the limited hard drives in your company? Do you need to transfer data from one drive to another, as a backup? Many people are so used to this necessity, that they consider it an unpleasant but unavoidable part of life. Hadoop distributed file system, HDFS, grows by adding servers. To you it looks like one hard drive. It is self-replicating (you set the replication factor) and thus provides redundancy as a software alternative to RAID.

  • Do your computations take an unacceptably long time? Are you forced to give up on projects because you don’t know how to easily distribute the computations between multiple computers? MapReduce helps you solve these problems. What if you don’t have the hardware to run the cluster? - Amazon EC2 can run MapReduce jobs for you, and you pay only for the time that it runs - the cluster is automatically formed for you and then disbanded.

  • But say you are lucky, and instead of maintaining legacy software, you are charged with building new, progressive software for your company's work flow. Of course, you want to have unlimited storage, solving this problem once and for all, so as to concentrate on what's really important. The answer is: you can mount HDFS as a FUSE file system, and you have your unlimited storage. In our cases studies we look at the successful use of HDFS as a grid storage for the Large Hadron Collider.

  • Imagine you have multiple clients using your on line resources, computations, or data. Each single use is saved in a log, and you need to generate a summary of use of resources for each client by day or by hour. From this you will do your invoices, so it IS important. But the data set is large. You can write a quick MapReduce job for that. Better yet, you can use Hive, a data warehouse infrastructure built on top of Hadoop, with its ETL capabilities, to generate your invoices in no time. We'll talk about Hive later, but we hope that you already see that you can use Hadoop and friends for fun and profit.

Once you start thinking without the usual limitations, you can improve on what you already do and come up with new and useful projects. In fact, this book partially came about by asking people how they used Hadoop in their work. You, the reader, are invited to submit your applications that became possible with Hadoop, and I will put it into Case Studies (with attribution :) of course.

7.3. Meet the Hadoop Zoo

QUINCE: Is all our company here?

BOTTOM: You were best to call them generally, man by man, according to the script.

Shakespeare, "Midsummer Night's Dream"

There are a number of animals in the Hadoop zoo, and each deals with a certain aspect of Big Data. Let us illustrate this with a picture, and then introduce them one by one.

Figure 7.3. The Hadoop Zoo

The Hadoop Zoo

HDFS - Hadoop Distributed File System

HDFS, or the Hadoop Distributed File System, gives the programmer unlimited storage (fulfilling a cherished dream for programmers). However, here are additional advantages of HDFS.

  • Horizontal scalability. Thousands of servers holding petabytes of data. When you need even more storage, you don't switch to more expensive solutions, but add servers instead.

  • Commodity hardware. HDFS is designed with relatively cheap commodity hardware in mind. HDFS is self-healing and replicating.

  • Fault tolerance. Every member of the Hadoop zoo knows how to deal with hardware failures. If you have 10 thousand servers, then you will see one server fail every day, on average. HDFS foresees that by replicating the data, by default three times, on different data node servers. Thus, if one data node fails, the other two can be used to restore the third one in a different place.

HDFS implementation is modeled after GFS, Google Distributed File system, thus you can read the first paper on this, to be found here:

More in-depth discussion of HDFS is here : Chapter 8, Hadoop Distributed File System (HDFS) -- Introduction


MapReduce takes care of distributed computing. It reads the data, usually from its storage, the Hadoop Distributed File System (HDFS), in an optimal way. However, it can read the data from other places too, including mounted local file systems, the web, and databases. It divides the computations between different computers (servers, or nodes). It is also fault-tolerant.

If some of your nodes fail, Hadoop knows how to continue with the computation, by re-assigning the incomplete work to another node and cleaning up after the node that could not complete its task. It also knows how to combine the results of the computation in one place.

More in-depth discussing of MapReduce is here : Chapter 9, Introduction To MapReduce

HBase, the database for Big Data

"Thirty spokes share the wheel's hub, it is the empty space that make it useful" - Tao Te Ching ( translated by Gia-Fu Feng and Jane English)

Not properly an animal, HBase is nevertheless very powerful. It is currently denoted by the letter H with a base clef. If you think this is not so great, you are right, and the HBase people are thinking of changing the logo. HBase is a database for Big Data, up to millions of columns and billions of rows.

Another feature of HBase is that it is a key-value database, not a relational database. We will get into the pros and cons of these two approaches to databases later, but for now let's just note that key-value databases are considered as more fitting for Big Data. Why? Because they don't store nulls! This gives them the appellation of "sparse," and as we saw above, Tao Te Chin says that they are useful for this reason.


Every zoo has a zoo keeper, and the Hadoop zoo is no exception. When all the Hadoop animals want to do something together, it is the ZooKeeper who helps them do it. They all know him and listen and obey his commands. Thus, the ZooKeeper is a centralized service for maintaining configuration information, naming, providing distributed synchronization, and providing group services.

ZooKeeper is also fault-tolerant. In your development environment, you can put the zookeeper on one node, but in production you usually run it on an odd number of servers, such as 3 or 5.

Hive - data warehousing

Hive: "I am Hive, I let you in and out of the HDFS cages, and you can talk SQL to me!"

Hive is a way for you to get all the honey, and to leave all the work to the bees. You can do a lot of data analysis with Hadoop, but you will also have to write MapReduce tasks. Hive takes that task upon itself. Hive defines a simple SQL-like query language, called QL, that enables users familiar with SQL to query the data.

At the same time, if your Hive program does almost what you need, but not quite, you can call on your MapReduce skill. Hive allows you to write custom mappers and reducers to extend the QL capabilities.

Pig - Big Data manipulation

Pig: "I am Pig, I let you move HDFS cages around, and I speak Pig Latin."

Pig is called pig not because it eats a lot, although you can imagine a pig pushing around and consuming big volumes of information. Rather, it is called pig because it speaks Pig Latin. Others who also speak this language are the kids (the programmers) who visit the Hadoop zoo.

So what is Pig Latin that Apache Pig speaks? As a rough analogy, if Hive is the SQL of Big Data, then Pig Latin is the language of the stored procedures of Big Data. It allows you to manipulate large volumes of information, analyze them, and create new derivative data sets. Internally it creates a sequence of MapReduce jobs, and thus you, the programmer-kid, can use this simple language to solve pretty sophisticated large-scale problems.

7.4. Hadoop alternatives

Now that we have met the Hadoop zoo, we are ready to start our excursion. Only one thing stops us at this point - and that is, a gnawing doubt, are we in the right zoo? Let us look at some alternatives to dealing with Big Data. Granted, our concentration here is Hadoop, and we may not give justice to all the other approaches. But we will try.

Large data storage alternatives

HDFS is not the only, and in fact, not the earliest or the latest distributed file system. CEPH claims to be more flexible and to remove the limit on the number of files. HDFS stores all of its file information in the memory of the server which is called the NameNode. This is its strong point - speed - but it is also its Achilles' heel! CEPH, on the other hand, makes the function of the NameNode completely distributed.

Another possible contender is ZFS, an open-source file system from SUN, and currently Oracle. Intended as a complete redesign of file system thinking, ZFS holds a strong promise of unlimited size, robustness, encryption, and many other desirable qualities built into the low-level file system. After all, HDFS and its role model GFS both build on a conventional file system, creating their improvement on top of it, and the premise of ZFS is that the underlying file system should be redesigned to address the core issues.

I have seen production architectures built on ZFS, where the data storage requirements were very clear and well-defined and where storing data from multiple field sensors was considered better done with ZFS. The pros for ZFS in this case were: built-in replication, low overhead, and - given the right structure of records when written - built-in indexing for searching. Obviously, this was a very specific, though very fitting solution.

While other file system start out with the goal of improving on HDFS/GFS design, the advantage of HDFS is that it is very widely used. I think that in evaluating other file systems, the reader can be guided by the same considerations that led to the design of GFS: its designers analyzed prevalent file usage in the majority of their applications, and created a file system that optimized reliability for that particular type of usage. The reader may be well advised to compare the assumptions of GFS designers with his or her case, and decide if HDFS fits the purpose, or if something else should be used in its place.

We should also note here that we compared Hadoop to other open-source storage solutions. There are proprietary and commercial solutions, but such comparison goes beyond the scope of this introduction.

Large database alternatives

The closest to HBase is Cassandra. While HBase is a near-clone of Google’s Big Table, Cassandra purports to being a “Big Table/Dynamo hybrid”. It can be said that while Cassandra’s “writes-never-fail” emphasis has its advantages, HBase is the more robust database for a majority of use-cases. HBase being more prevalent in use, Cassandra faces an uphill battle - but it may be just what you need.

Hypertable is another database close to Google's Big Table in features, and it claims to run 10 times faster than HBase. There is an ongoing discussion between HBase and Hypertable proponents, and the authors do not want to take sides in it, leaving the comparison to the reader. Like Cassandra, Hypertable has fewer users than HBase, and here too, the reader needs to evaluate the speed of Hypertable for his application, and weigh it with other factors.

MongoDB (from "humongous") is a scalable, high-performance, open source, document-oriented database. Written in C++, MongoDB features document-oriented storage, full index on any attribute, replication and high availability, rich, document-based queries, and it works with MapReduce. If you are specifically processing documents and not arbitrary data, it is worth a look.

Other open-source and commercial databases that may be given consideration include Vertica with its SQL support and visualization, Cloudran for OLTP, and Spire.

In the end, before embarking on a development project, you will need to compare alternatives. Below is an example of such comparison. Please keep in mind that this is just one possible point of view, and that the specifics of your project and of your view will be different. Therefore, the table below is mainly to encourage the reader to do a similar evaluation for his own needs.

Table 7.1. Comparison of Big Data

DB Pros/ConsHBaseCassandraVerticaCloudTranHyperTable
ProsKey-based NoSQL, active user community, Cloudera support Key-based NoSQL, active user community, Amazon's Dynamo on EC2Closed-source, SQL-standard, easy to use, visualization tools, complex queries Closed-source optimized on line transaction processing Drop-in replacement for HBase, open-source, arguably much faster
ConsSteeper learning curve, less tools, simpler queriesSteeper learning curve, less tools, simpler queriesVendor lock-in, price, RDMS/BI - may not fit every application Vendor lock-in, price, transaction-optimized, may not fit every application, needs wider adoptionNew, needs user adoption and more testing
NotesGood for new, long-term development Easy to set up, no dependence on HDFS, fully distributed architectureGood for existing SQL-based applications that needs fast scaling Arguably the best OLTP To be kept in mind as a possible alternative

7.5. Alternatives for distributed massive computations

Here too, depending upon the type of application that the reader needs, other approaches make prove more useful or more fitting to the purpose.

The first such example is the JavaSpaces paradigm. JavaSpaces is a giant hash map container. It provides the framework for building large-scale systems with multiple cooperating computational nodes. The framework is thread-safe and fault-tolerant. Many computers working on the same problem can store their data in a JavaSpaces container. When a node wants to do some work, it finds the data in the container, checks it out, works on it, and then returns it. The framework provides for atomicity. While the node is working on the data, other nodes cannot see it. If it fails, its lease on the data expires, and the data is returned back to the pool of data for processing.

The champion of JavaSpaces is a commercial company called GigaSpaces. The license for a JavaSpaces container from GigaSpaces is free - provided that you can fit into the memory of one computer. Beyond that, GigaSpaces has implemented unlimited JavaSpaces container where multiple servers combine their memories into a shared pool. GigaSpaces has created a big sets of additional functionality for building large distributed systems. So again, everything depends on the reader's particular situation.

GridGain is another Hadoop alternative. The proponents of GridGain claim that while Hadoop is a compute grid and a data grid, GridGain is just a compute grid, so if your data requirements are not huge, why bother? They also say that it seems to be enormously simpler to use. Study of the tools and prototyping with them can give one a good feel for the most fitting answer.

Terracotta is a commercial open source company, and in the open source realm it provides Java big cache and a number of other components for building large distributed systems. One of its advantages is that it allows existing applications to scale without a significant rewrite. By now we have gotten pretty far away from Hadoop, which proves that we have achieved our goal - give the reader a quick overview of various alternatives for building large distributed systems. Success in whichever way you choose to go!

7.6. Arguments for Hadoop

We have given the pro arguments for the Hadoop alternatives, but now we can put in a word for the little elephant and its zoo. It boasts wide adoption, has an active community, and has been in production use in many large companies. I think that before embarking on an exciting journey of building large distributed systems, the reader will do well to view the presentation by Jeff Dean, a Google Fellow, on the "Design, Lessons, and Advice from Building Large Distributed Systems" found on SlideShare

Google has built multiple applications on GFS, MapReduce, and Big Table, which are all implemented as open-source projects in the Hadoop zoo. According to Jeff, the plan is to continue with 1,000,000 to 10,000,000 machines spread at 100s to 1000s of locations around the world, and as arguments go, that is pretty big.
